Name: Winmate M101P 10.1" Intel Pentium Sunlight Readable Rugged Tablet w/ PCAP Touch
SKU: M101P

Winmate

Winmate M101P 10.1″ Intel Pentium Sunlight Readable Rugged Tablet w/ PCAP Touch

M101P

10.1” 1920×1200 IPS LED Panel with P-Cap Touch
Long battery life with Intel Pentium N4200 Apollo Lake processor
IP65 water and dust proof
Optional Integrated Barcode or RFID Reader
Dual Camera Design: 8MP Main camera / 2MP Webcam
Optional Expansion port for USB / RS232 connection
Hot-Swappable Battery Design / Optional high capacity battery pack
2 Programmable function keys
With optical bonding and anti-glare solution for sunlight readability

Product Code: M101P

Categories: Mobile Computing, Rugged Tablet PCs, Winmate

Range: Winmate

Details

Winmate's M101P is a rugged tablet PC with robust set of features designed to withstand industrial use while providing high tech solutions that increase productivity, improve safety, and reduce operational costs. The processing power comes from Intel's Apollo Lake processor paired with genuine Intel graphics for high performance. The tablet features a brilliant, in-plane switching with direct optical bonding, projected capacitive touch screen, which is outdoor viewable and offers 1920 x 1200 pixel resolution. Weighing at just 1200 grams (approx. 2.65 pounds) the M101P delivers lightweight mobility in a rugged tablet.

Ordering Info

M101P-ME	Housing enhanced with anti-microbial properties
M101PR	Resistive Touch

Downloads

Winmate M101P Datsheet (PDF)

0.72MB

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Custom Design

Specification

Size	10.1″
Brightness	800 nits(typ.)
Resolution	1920×1200 WUXGA
Contrast Ratio	33.33402778
Touch	Multi-Touch Projected Capacitive Touchscreen (supports Rain, Glove, Stylus Modes)
Viewing Angle	85/85/85/85
Panel Viewability	Optical Bonding for Sunlight Viewability, Default anti-glare solution
Processor	Intel Pentium N4200 Apollo Lake Processor 1.10 GHz, up to 2.50 GHz with turbo boost technology
Chipset	Intel® HD Graphics 505
Memory	4GB SODIMM LPDDR4 (up to 8GB)
Storage	128GB SSD (Options up to 512GB)Additional storage available with micro SDXC card slot
Audio	1 x Built-in Mic with Noise Cancellation, 2 x 1W Speaker
WLAN	802.11 a/b/g/n/ac WiFi
Bluetooth	Bluetooth 5.0
WWAN	Optional 4G/ LTE
GPS	GPS, GLONASS
I/O	1 x 19-pin docking connector, 1 x micro HDMI, 1 x USB 3.0 (Type A), 1 x USB 3.0 (Type C) 2, 1 x Power Jack, 1 x Micro SDXC slot, 1 x Audio combo connector (Mic in or Line Out), 1 x Expansion connector for USB 2.0/ Full RS232(Optional), 1 x Micro SIM card slot, 1 x Mini PCIe for WWAN Module
Control Button	1 x Power, 1 x Home, 2 x Volume, 2 x Programmable Function Keys
LED indicator	Power, Battery, HDD Access, RF
Dimensions (W x L x H)	271.9 x 198.3 x 19.5 mm (10.7 x 7.76 x 0.77 inches)
Net Weight (kg)	1.2 kg (2.65 lbs) with standard battery, 1.4 kg (3.1 lbs) with optional high capacity battery
Operating Temperature	-20°C to 60°C (AC mode), -10°C to 50°C (Battery mode)
Storage Temperature	-30°C to 70°C (-22°F to 158°F)
IP Proof	IP65
Operating Humidity	10% to 90% RH, non-condensing
Shock	MIL-STD-810G Method 516.6 Procedure I
Vibration	MIL-STD-810G Method 514.6 Procedure I
Drop	MIL-STD-810G Method 516.6, 4 ft to concrete*
Power Input	12~19V DC
Battery	Hot-swappable 7.7V, typ. 5900 mAh Li-Polymer Battery (2S1P)7.4V, typ. 10280 mAh Li-Polymer Battery (2S2P, Optional)
Adapter	100-240V, 50-60Hz, 19V DC
Battery Operating Time	Std. Battery: 9 hours*, High Capacity Battery: 16 hours*
OS	Windows 10 IoT Enterprise (64 bit)
Camera	8MP Auto-Focus Camera with LED Light at rear / 2MP Camera at front side
Data Capture	Optional 1D/2D Barcode Reader, Optional HF RFID Reader, Optional add-on UHF RFID Reader or Smart Card Reader
Security	Trusted platform module (TPM) V2, Kensington Lock
Mobile Device Management	SOTI Mobicontrol compatible

Screen Size	1" to 10", 10.1"
Touch Technology	Projected Capactive
Ingress Protection	IP65
Brightness	800nit, Standard
