ECX-3400-PEG
Vecow ECX-3400 PEG 13th Gen 24-Core Intel Core i9/i7/i5/i3/ 12th Gen 16-Core Intel Core i9/i7/i5/i3 Edge AI Computer w/ 1 x x16 PCIe, 1x x4 PCIe
ECX-3400-PEG
- Workstation-grade Platform : 13th/12th Gen Intel Core i9/i7/i5/i3 Processor (Raptor Lake-S/Alder Lake-S) running with Intel R680E Chipset, max 65W TDP CPU
- DDR5 4800MHz Memory supports up to 64GB, optional ECC supported
- Supports outstanding AI computing productivity by NVIDIA/AMD graphics card, up to 200W power budget
- USB 3.2 Gen 2×2 offers a max speed of 20Gbps data transfer
- DC 12V to 50V wide range power input, Software Ignition Control
- 4 Independent 2.5GigE IEEE 802.3at PoE+ LAN, 2 GigE LAN
- Expansion : 1 PCIe x16 slot with x16 signal, 1 PCIe x16 slot with x4 signal , 1 M.2 Key B, 1 M.2 Key E, 1 Mini PCIe
- Supports multiple 5G/WiFi/BT/4G/LTE/GPRS/UMTS
- Supports Intel vPro, TCC, Time-Sensitive Networking (TSN), and TPM 2.0
- Storage : 4 front-access 2.5″ SSD Tray, M.2 Key M
ECX-3400-PEG
Details
Featuring 13th/12th Gen Intel Core i9/i7/i5/i3 processor (Raptor Lake/Alder Lake) and running with Intel® R680E Chipset, Vecow ECX-3000 PEG Series delivers workstation-grade performance, with up to 36% CPU performance improved. The series is equipped with up to 4 PCIe expansion slot that supports max 200W power of NVIDIA® or AMD graphics engine and allows for expansions with 1 Mini PCIe and 2 M.2. Support for PCIe 5.0 and DDR5 4800HMz memory up to 64GB, Vecow ECX-3000 PEG Series offers a robust combination of performance and flexibility to facilitate AIoT applications such as Robotic Control, Smart Manufacturing, In-Vehicle Computing, and any Edge AI applications.Downloads
