QH55H

55″ QLED Signage Screen with 4K & No Bezel

End of Life

Brand: Samsung
Usage: 16/7
Bezel Size: Edge-to-Edge
600 NITS brightness
QLED for 1.07 Billion colours (True Display 10bit)
Viewable Area: 1209.6mm (W) x 680.4mm (H)
Size: 1238.6mm (W) x 714.2mm (H) x 59mm (D)

Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.

Product Code: QH55H

Categories: End of Life Products

Range: Samsung

Details

Truly, one of the ultimate signage display screens on the market today. The QH55H is a 55 inch bezel-less, 4K (UHD) commercial screen designed for 16/7 usage. Samsung's QLED quantum dot technology gives the screen 1.07 billion colours to present a lifelike visual experience with deeper blacks and brilliant whites for the ultimate in content presentation.

Connectivity is provided by 1 x Display Port 1.2, 2 x HDMI 2.0, 1 x HDCP 2.2 and 2 x USB 2.0, plus 2 x built in 10W speakers. The QH55H also features an internal player with a Coretex A72 1.7GHz Quad Core CPU powering the Linux based Tizen 3.0 operating system for content playback. TIZEN 3.0’s rigid three-layer security structure also restricts file data access to a limited user base, and meets the security standards required for government, financial and other information-based businesses reliant on information protection.

Ordering Info

QH55H – 55″ QLED Signage Screen with 4K Resolution

Downloads

QHH Datasheet (PDF)

3.01MB

QH55H Specsheet (PDF)

0.17MB

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Custom Design

Specification

Diagonal Size: 55″
Resolution: 3840*2160 (4K UHD)
Pixel Pitch(mm): 0.105 x 0.315
Active Display Area(mm): 1209.6(H) x 680.4(V)
Brightness(Typ.): 600 nit
Contrast Ratio: 6000:1
Viewing Angle(H/V): 178/178
Response Time(G-to-G): 6ms
Display Colors: 1.07 B
Speaker Type: Built in Speaker(10W + 10W)
RGB: Display Port 1.2
Video: HDMI 2.0 (2)
HDCP: HDCP 2.2
USB: USB 2.0 x 2
AC 100 – 240 V~ (+/- 10 %), 50/60 Hz
Weight: 17.3kg
VESA: 400 x 400
Operating Temp: 0 ℃ ~ 40 ℃
Processor: Coretex A72 1.7GHz Quad-Core CPU
Memory: 2.5GB LPDDR4 1.5GHz 64bit
Storage: 8GB (3.88GB Occupied by O/S, 4.12GB Available)
OS: Tizen 3.0 (VDLinux)

Screen Size	51" to 60", 55"
