FR QH55H
55″ QLED Signage Screen with 4K & No Bezel
End of Life
- Brand: Samsung
- Usage: 16/7
- Bezel Size: Edge-to-Edge
- 600 NITS brightness
- QLED for 1.07 Billion colours (True Display 10bit)
- Viewable Area: 1209.6mm (W) x 680.4mm (H)
- Size: 1238.6mm (W) x 714.2mm (H) x 59mm (D)
Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.
Details
Truly, one of the ultimate signage display screens on the market today. The QH55H is a 55 inch bezel-less, 4K (UHD) commercial screen designed for 16/7 usage. Samsung's QLED quantum dot technology gives the screen 1.07 billion colours to present a lifelike visual experience with deeper blacks and brilliant whites for the ultimate in content presentation.
Connectivity is provided by 1 x Display Port 1.2, 2 x HDMI 2.0, 1 x HDCP 2.2 and 2 x USB 2.0, plus 2 x built in 10W speakers. The QH55H also features an internal player with a Coretex A72 1.7GHz Quad Core CPU powering the Linux based Tizen 3.0 operating system for content playback. TIZEN 3.0’s rigid three-layer security structure also restricts file data access to a limited user base, and meets the security standards required for government, financial and other information-based businesses reliant on information protection.
Ordering Info
- QH55H – 55″ QLED Signage Screen with 4K Resolution
Downloads
System Integration
Please ask about how we can configure your solution
Global Operations
We deliver and support products via offices globally
Full Warranty
Industry leading warranties on all solutions as standard
Technical Support
Experienced engineers are on hand to support your project
Can't Find What You Want?
Specification
- Diagonal Size: 55″
- Resolution: 3840*2160 (4K UHD)
- Pixel Pitch(mm): 0.105 x 0.315
- Active Display Area(mm): 1209.6(H) x 680.4(V)
- Brightness(Typ.): 600 nit
- Contrast Ratio: 6000:1
- Viewing Angle(H/V): 178/178
- Response Time(G-to-G): 6ms
- Display Colors: 1.07 B
- Speaker Type: Built in Speaker(10W + 10W)
- RGB: Display Port 1.2
- Video: HDMI 2.0 (2)
- HDCP: HDCP 2.2
- USB: USB 2.0 x 2
- AC 100 – 240 V~ (+/- 10 %), 50/60 Hz
- Weight: 17.3kg
- VESA: 400 x 400
- Operating Temp: 0 ℃ ~ 40 ℃
- Processor: Coretex A72 1.7GHz Quad-Core CPU
- Memory: 2.5GB LPDDR4 1.5GHz 64bit
- Storage: 8GB (3.88GB Occupied by O/S, 4.12GB Available)
- OS: Tizen 3.0 (VDLinux)
| Screen Size | 51" to 60", 55" |
|---|
