ATC 3750-IP7-WI6CR

Name: Nexcom ATC 3750-IP7-WI6CR NVIDIA Jetson AGX Orin Solution Performance Edge AI Computing
SKU: ATC 3750-IP7-WI6CR

Nexcom

Nexcom ATC 3750-IP7-WI6CR NVIDIA Jetson AGX Orin Solution Performance Edge AI Computing

ATC 3750-IP7-WI6CR

Built-in NVIDIA Jetson AGX Orin SOM, up to 200/275 TOPS (INT8) performance
Designed to be IP67 rated, rugged, and compact
6-port GbE PoE+ for IP CAM/LiDAR sensors, optional 1-port 10GbE
HEVC/H.265 hardware DECODE, supporting up to 7 x 4K30
Wide range operating temperature of -25°C~70°C
Ultra-speed PCIe 4.0 x4 NVMe SSD for data integrity
Expansible for GNSS, LTE/5G NR & Wi-Fi 5/6
24~110VDC with ignition control & OCP/OVP for Rail
NEXCOM Acceleration Linux (NAL) integrated w/ JetPack 5.1.1
Military standard of MIL-STD-810H for anti-vibration/shock
CE/FCC, UKCA, EN45545-2, EN50155(EN50121-3-2, EN61373, OT3, Certified

Product Code: ATC 3750-IP7-WI6CR

Categories: Nexcom, NVIDIA Jetson, NVIDIA Jetson Systems

Range: Nexcom

Details

AI has become an essential component of automated vehicle technologies. With its built-in high performance NVIDIA Jetson AGX Orin SOM, the ATC 3750-IP7-WI6CR can deliver up to 200/275 TOPS workload on Artificial Intelligence (AI) processing and inference, supporting AI aided transportation applications such as railway safety assurance which can be collaborating with existing ATP/ATO. Thanks to NEXCOM excellent thermal solutions, ATC 3750-IP7-WI6CR can working through its defined TDP (15W~60W) at the harsh environments without fan kit to achieve 200/275 TOPS workload performance. The ATC 3750-IP7-WI6CR is a IP67 rated, rugged, compact-size rail AI powered computer that features 24~110VDC with IGN control, 6 PoE+ and one optional 10GbE for accessing IP CAM/LiDAR sensors, and rich peripheral ports, USB 3.2, isolation CANBus, RS232, Console, DI/DO, OTG and HDMI. With the installation of 5G NR, Wi-Fi 5/6 modules, the ATC 3750-IP7-WI6CR can collaborate with CPS for AI model re-training, making it suitable for deployment sophisticated in railway/rolling stock applications. In harsh environments, the ATC 3750-IP7-WI6CR can operate at a wide temperature range of -25~70°C and meet the MIL-STD-810H military standard for anti-vibration and shock. For regulation, the ATC 3750-IP7- WI6CR is certified by CE/FCC Class A, UKCA and EN50155/EN45545-2.

Ordering Info

ATC 3750-IP7-WI6CR (P/N: 10AT0375011X0): NVIDIA Jetson AGX Orin SOM, 32GB LPDDR5, 64GB eMMC, 6 x PoE+(X-coded), 2 x USB 3.2, 2 x RS232, OTG/Console, IP67, Rail, isolation 24~110Vdc

ATC 3750-IP7-WI6CR-64 (P/N: 10AT0375012X0): NVIDIA Jetson AGX Orin SOM, 32GB LPDDR5, 64GB eMMC, 6 x PoE+ (X-coded), 2 x USB 3.2, 2 x RS232, OTG/Console, IP67, Rail, isolation 24~110Vdc

Downloads

Datasheet (ATC 3750-IP7-WI6CR) (PDF)

0.79MB
