G330

Name: Giada G330 Digital Signage PC with 6 Display Outputs Intel 6th Gen i7/i5/i3 CPU
SKU: G330

Giada

Giada G330 Digital Signage PC with 6 Display Outputs Intel 6th Gen i7/i5/i3 CPU

G330

Brand: Giada
Intel 6th Generation Core CPU options
Radeon HD7750 GPU with 6 x DisplayPorts
6 x USB, 2 x LAN, 2 x COM
Size: 350mm (W) x 235.5mm (D) x 43mm (H)

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

I require customisation *
Please share some background information on your project to help us ensure we’re proposing the best solution *
What processing level is required? *
How much RAM do you require? *
How much storage is required? *
What is the project timeline? *
What operating system would you like to use? *
Do you need any Wi-Fi or Cellular? *
- Wi-Fi
- Cellular
Do you need wide-temperature components? *
- Yes
- No
Do you need a mounting kit? *
Do you need an AC-DC power supply? *
Do you need any additional expansion modules? *

Product Code: G330

Categories: Digital Signage Computers, Giada

Range: Giada

Details

The Giada G330 digital signage computer from Giada has impressive performance derived from the 6th Generation Intel Core i7/i5/i3 (Skylake-S) CPU with the Radeon HD7750 GPU handling 6 x display ports. It is built for complex and demanding digital signage applications and takes over as Giada’s flagship PC. Windows and Linux are both supported with 16GB on-board memory. The G330 is a great choice if you need multiple outputs, it runs up to 6 independent displays (4 x 4K displays or 6 x Full HD). I/O on this powerful rugged digital signage system includes 6 x USB (1 x USB Type-C 3.0, 1 x USB 3.0 & 4 x USB 2.0), 2 x LAN, 2 x COM plus there is expansion available via 1 x Full length Mini PCIe for mSATA support and 1 x Full or Half length Mini PCIe for communication module support.

Downloads

Giada G330 Datasheet (PDF)

0.68MB

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Custom Design

Specification

CPU	Intel® LGA1151 Socket 7th/6th Gen. Processor
BIOS	AMI Source Code
Chipset	H110
Type	DDR3L-1600MHz
Socket	2 x SO-DIMM
Max Size	32GB
GPU	AMD Radeon™ 7750 GPU,DDR5 2GB
Graphic Engine	DirectX11.1, OpenGL4.2 ,OpenCL 1.2
DP	3 x 2DP Landscape Max.5760 x 2160
Controller	Intel® I219/I211 Gigabit Ethernet
Interface	2 x RJ45
USB	1 x Type-C USB 3.0, 1 x USB 3.0, 4 x USB 2.0
Serial Port	2 x RS232
Audio	1 x MIC-IN, 1 x AUDIO-OUT
Mini-PCIe1#	1 x Full-size Mini-PCIe for mSATA
Mini-PCIe2#	1 x Full-size Mini-PCIe for WiFi/BT
SATA	1 x 2.5″ SATA
mSATA	1 x Full-size mSATA
WatchDog Timer	0~255 Second Time Out Support
Auto Power On	Power Activated Automatically Start
RTC	Set Up Independently Every day, A Week as a Cycle
Remote Control	By IR Controller for Power On
Windows	Windows 7/8.1/10(64-bit)
Linux	Supported
Power Type	AC
Input Voltage	110V~220V
Dimensions (W × D × H)	350mm x 235.2mm x 43mm(13.78″x9.26″x1.69″)
Construction	Metal
Mounting(Optional)	Wall Mounting and VESA Mounting(JZ300)
Color	Black
Operating Temperature	0℃ ~ 40℃ ( 32 ℉ ~ 104 ℉ ) at 0.7m/s Air Flow
Relative Humidity	95%@40℃ (non-condensing)
Certification	CE, FCC Class B, CCC
