Pad-Ex 01 P8 DZ2

Ecom Pad-Ex 01 P8 DZ2 Zone 2 and Division 2 Windows Tablet

End of Life

  • hd 1920×1080: High Resolution Display
  • High Speed and Efficiency for the Most Demanding Tasks
  • Service Level Agreement
  • Custom Software Load
  • Sunlight Readable Display
  • Capacitive Multi-Touch Screen
  • Data Collection
  • 1D / 2D Barcode Scanner (optional)
  • 5MP Auto Focus Camera with LED Flash Light

Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.

-
+

Details

While being given its level of ruggedness, Pad-Ex® 01 P8 DZ2 meets all the environmental requirements and supports the 8th generation Intel® Core™ i5 processor. It also provides battery life up to 7 hours and Windows® 10 Pro support.

Combining robust features and a large screen size, superior performance is ideal for field operatives of all sectors to complement or even substitute Desktop PC, laptop or wall mounted display.

Supporting such an ultra compact form factor, Pad-Ex® 01 P8 DZ2 manages to fully meet IP65, 4 feet drop and MIL-STD 810G for vibration. With its additional display protection it offers complete protection against the harsh environment field workers face and minimizes burden on their bodies during long hours of work.

As private 4G / LTE wireless connectivity is increasingly adopted within hazardous areas, Pad-Ex® 01 P8 DZ2 ensures access is fast and seamless – enabling users to quickly access the information needed to perform the task at hand. For sites without WiFi or 4G access in the field, Pad-Ex® 01 P8 DZ2 provides up to 256GB of SSD memory to meet your on-board data storage needs, backed by an i5 to ensure your applications run as smoothly and efficiently as possible.

Central to ecom's Mobile Worker concept, the latest Bluetooth standards are also supported by Pad-Ex® 01 P8 DZ2, allowing realtime connectivity to both Bluetooth SmartReady Low Energy 5.0 (BLE) devices as well as older legacy Bluetooth devices. This allows the mobile worker to benefit from expanded Pad-Ex® 01 P8 DZ2 capabilities such as data collection and measuring/monitoring devices, headsets, AutoID, and Bluetooth Beacons for localization.

Once your work in the field is done, Pad-Ex® 01 P8 DZ2 transforms into your PC via the optional desktop docking interface, allowing seamless integration into your office and corporate networks.

Ordering Info

Ecom Pad-Ex 01 P8 DZ2 Zone 2 and Division 2 Windows Tablet

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Specification

  IP65
Drop MIL-STD 810G 516.6 Procedure IV
  6 drops from 4 feet height to plywood over concrete
Vibration MIL-STD 810G 514.6 Procedure I Cat. 24,
  Fig. 514.6E-1
Environment Temperature Operating: -10°C – 55°C (14°F – 131°F)
  Storage: -10°C – 55°C (14°F – 131°F)
Humidity Operating: 5% – 95%
Altitude Operating: 15,000 feet (approx. 4,572 m)
Operating System Full Windows 10 64 Bit / Windows 10 Pro
CPU Intel Broadwell i5 series
Memory One DDR4 socket for 8GB
Storage M2-SATA SSD 256GB
Display 11.6″ HD (1920 x 1080) LCD Panel
  Capacitive Multi-Touch
  Optical Bonding Sunlight Readable LCD
  Ambient Light Sensor
Sensor Built-in G sensor, Gyroscope, and E-Compass
Audio Integrated speaker x 1
  Integrated microphone – Intel® High Definition Audio Compliant
Camera 2MP Front Facing Camera
  5MP Rear Camera with auto focus and LED flashlight
  support Geo Tagging (Optional)
Communication 4G LTE (Optional)
  GPS (Optional)
  Intel Wireless AC9260 802.11 a/b/g/n/ac
  Bluetooth 5.0
Data Collection 1D / 2D Barcode Scanner (Optional)
VO Ports Two USB 3.0
  One Headphone out / Mic-in jack
  One Docking Connector
  One Expansion Connector for Expansion Modules
  Two RF pass-through connectors for WWAN & GPS
Expansion Slots One Micro SD Card slot support SDHC & SDXC
  One SIM Card
Button Power
  Volume
  Windows Touch button
  Barcode / Camera Touch Button
  Programmable Touch Button
Battery One 3,950 mAh Li-Polymer battery pack: 7hrs
  7,800 mAh (Optional) Li-Polymer battery pack: 14hrs
AC Adaptor 19 V; 3,42 A; 65 W
Dimension 298 mm x 192 mm x 20 mm (11.75″ x 7.55″ x 0.78″)
Weight 1.2 Kg (~42.32 oz)
ATEX (Europe)  II 3G Ex ic IIC T4 Gc IP64
  II 3D Ex ic IIIB T135°C Dc IP64
IECEx (International) Ex ic IIC T4 Gc IP64
  Ex ic IIIB T135°C Dc IP64
SGS (CEC / NEC) Class I, Division 2, Groups A,B,C,D T4
  Class I, Zone 2, Group IIC, T4
