JCO-3000-ORN-B

C&T Solution JCO-3000-ORN-B NVIDIA Jetson Orin NX 8G/16G or Nano 8G/4G Mid-Range AI Computer with 8x DI + 8x DO

  • NVIDIA Jetson Orin NX 8 GB/16 GB or Nano 8 GB/4 GB GPU with 32 Tensor Cores
  • 1x HDMI 2.0, 3840 x 2160 @ 60Hz
  • 4x GbE RJ45 LAN with Optional PoE option
  • 1x External Dual Nano SIM socket
  • 1x M.2 (M Key, 2242/2280, PCIex 4,Support NVMe)
  • 4x USB 3.0 Gen 2, 1x USB Type-C (Flash)
  • 8x DI + 8x DO with isolation
  • 12 to 24VDC Wide Range Power Input Supporting AT/ATX Mode
  • Wide Operating Temperature -20°C to 55°C (25W, NX Module)

Available

Details

The C&T Solution JCO-3000-ORN-B is a Mid range AI computer powered by NVIDIA Jetson Orin NX 8G/16G or Nano 8G/4G GPU with 32 Tensor Cores. It operates at -20°C to 60°C and stores within -30°C to 85°C. It has a power input of 9 to 36 VDC and also has mounting options of DIN railing and Wall mount.

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Processor Type 6 Cores
GPU Integrated GPU
Cooling Type Fanless
Serial Ports (COM) 2 Ports, RS232/422/485
USB Ports 4x USB 3.0
Ethernet Ports (LAN) 4x 1G
Wireless Wi-Fi
CAN Bus Yes
Video Ports 1x HDMI
Digital I/O 16 DIO
Storage Type 1x M.2
Expansion Type 2x M.2
Input Voltage 9-36 VDC
Ignition Control Yes
Mounting Options DIN-Rail, Wall-mount
Market Certifications CE/FCC
OS Support Linux

Delivery Information

Orders dispatched from Assured Systems USA will be delivered using FedEx.

Orders placed by EMEA customers will be delivered by DHL from Assured Systems UK.

Payment Methods & Options

Accepted payment methods for US customers include bank transfer, VISA or Mastercard in USD.

Accepted payment options for EMEA customers include VISA, Mastercard or bank transfer in GBP.

C&T Solution: Warranty and Service Information

As standard, we offer a 2 year warranty on all C&T Solution products sold and distributed within EMEA (including the UK) and US regions when purchased directly from Assured Systems. We are proud to be an official C&T Solution partner and can supply products with secure and certified delivery directly from our UK and USA headquarters. Warranties can also be extended if required, please contact our sales team for options.
