AVerMedia SE5810 1-CH HDMI/3G-SDI Compact Single-Channel Video Encoder
SE5810
- Support remote NAS storage or local storage to an external USB device/SD Card
- Stream and record up to 1080p60, simultaneously
- Provide an audio output for monitoring purposes
- Support preview function
- Encode HEVC directly
- Support PoE (Power over Ethernet)
- Provide physical buttons (stream, record and switch source) for intuitive operation
Details
The AVerCaster SE5810 is a single-channel video encoder that allows any independent Full HD video streams to be broadcasted or recorded at the same time. SE5810 takes HDMI or 3G-SDI video sources up to 1920 x 1080 Full HD resolution (maximum of 1920 x 1200, RB) and encodes a video stream of the same or various bitrates for broadcasting or recording. With powerful single H.265 high-profile codecs, SE5810 records live Full HD video at high quality for VoD playback and simultaneously broadcasts it via popular streaming service providers such as Facebook Live to an unlimited number of viewers. Powerful in performance, small in size—the AVerCaster SE5810 is ready to contribute to countless on-LAN and Internet video streaming applications. Attract and astonish the audience with amazing, crystal clear 1920 x 1080 Full HD resolution (maximum of 1920 x 1200, RB) video content. The AVerCaster SE5810 is a professional-grade encoder without the price burden. While lowering the overall cost when deploying your applications, it is all managed through a user-friendly management interface that speeds up the setup process. To broadcast video content to a global audience, the AVerCaster SE5810 has strong integration with CDN services including Facebook Live and YouTube. AVerMedia provides total and extremely comprehensive customization services. From CDN integration to specific API development and even proprietary protocol design, AVerMedia can help fulfill many unique requirements from a wide variety of applications. AVerCaster’s intuitive Web UI allows for a short learning curve and effortless operation. With its customizable setup, this web UI makes for more flexible and easy management, providing a very efficient and frustration-free professional setup of the AVerCaster SE5810 from any web browser within the same network regardless of the client device.
Downloads
System Integration
Please ask about how we can configure your solution
Global Operations
We deliver and support products via offices globally
Full Warranty
Industry leading warranties on all solutions as standard
Technical Support
Experienced engineers are on hand to support your project
Can't Find What You Want?
Specification
| Video Interface | HDMI 1.4b x 1, 3G-SDI x 1Audio embedded |
| Audio Interface | 3.5mm Line-in x 1, 3.5mm Line-out x 1 |
| Channels | 1 |
| Streaming or Recording Resolution | 640 x 480 to 1920 x 1080, 1920 x 1200 (RB, reduced blanking) |
| Video Encoder | H.265, H.264 |
| Audio Encoder | AAC |
| Recording File Format | MP4, MOV, TS |
| Protocol | TCP, UDP, RTMP, RTP, RTSP, RTMPS |
| Support Browser | Chrome |
| Support CDN | YouTube, Facebook Live |
| Preview Output | HDMI 1.4b |
| Streaming and Recording | 1 to 1 Mode: 1 stream audio/video input, encode setting and same streaming protocol/recording.1, 1, 1 Mode: Simultaneous streaming and recording from the same video/audio source. Recording to network mapped drive from NAS and Windows shared folders. |
| Physical Buttons | Stream, Record, Switch Source |
| Connectivity | Ethernet x 1, RS-485 |
| Storage | NAS, USB 3.0 for local storage, SD card slot for local storage |
| Power | Locking power supply 12V/5A; PoE (Power over Ethernet) |
| Accessory | Power adapter x 1, Power cord x 1, Quick guide x 1 |
| Integration | API for integration and remote control via Web UI |
| Operating Environment | 0–50°C (32–122°F), Humidity: 0–80% RHNC |
| Storage Environment | -40–70°C (-40–158°F), Humidity: 0–90% RHNC |
| Dimensions (L x W x H) | 213.5mm x 179.2mm x 41mm, (8.41” x 7.56” x 1.61”) |
| Weight | 1131 g (2.49 lbs) |
