D115OXB

Name: Avermedia D115OXB NVIDIA Jetson Orin NX Edge AI Computer 8GB/16GB 1 x HDMI 4K P60
SKU: D115OXB

AVerMedia

Avermedia D115OXB NVIDIA Jetson Orin NX Edge AI Computer 8GB/16GB 1 x HDMI 4K P60

D115OXB

Embedded NVIDIA Jetson Orin NX/Orin Nano module
2x GbE, 3x USB 3.0, 1x HDMI output
20 pins: 2x I2C, 1x UART, 4x GPIOs, 1x CAN (EU terminal block)
2x M.2 for Wi-Fi and SSD
Operating temperature: 0°C ~ 60°C (TBD)
Dimension: W: 126mm x L: 96mm x H: 74mm

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

I require customisation *
Please share some background information on your project to help us ensure we’re proposing the best solution *
What processing level is required? *
How much RAM do you require? *
How much storage is required? *
What is the project timeline? *
What operating system would you like to use? *
Do you need any Wi-Fi or Cellular? *
- Wi-Fi
- Cellular
Do you need wide-temperature components? *
- Yes
- No
Do you need a mounting kit? *
Do you need an AC-DC power supply? *
Do you need any additional expansion modules? *

Product Code: D115OXB

Categories: AVerMedia, Embedded Box PCs, Fanless Embedded PCs, Fanless Industrial PCs, GPU Computing, NVIDIA Jetson Orin NX Systems, NVIDIA Jetson Systems

Range: AVerMedia

Details

AVerMedia’s D115OXB/D115ONB is the next generation of AI Box PC that is designed with the NVIDIA® Jetson Orin NX/Orin Nano module. Suited for situations with spatial concerns, this high inference AI Box comes in at a compact 126mm (W) x 96mm (L) x 74mm (H) housing. And with a fanless design, the thermally optimized housing is capable of operating at 0 ~ 60°C(TBD) while running virtually silently.

We understand that every situation has a set of unique requirements, and this is the reason the D115OXB/D115ONB is designed with a rich assortment of I/O ports. From 2x 2 Lane MIPI CSI-2 Input (internal), to 1x HDMI output, and 2x GbE RJ-45, you can rest assured that the D115OXB/D115ONB carries key I/O ports required for your unique application. And if you require additional customizations, our customer-dedicated team will be happy to support you with rapid deployment.

Downloads

Datasheet (D115OXB) (PDF)

0.9MB

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Custom Design

Processor Type	RISC, up to 6 Cores, RISC, up to 8 Cores
GPU	Integrated GPU
Cooling Type	Fanless
USB Ports	1x USB 2.0, 3x USB 3.2
Ethernet Ports (LAN)	2x 1G
Wireless	Wi-Fi
Video Ports	1x HDMI
Storage Type	1x NVMe
Operating Temperature	Standard OT: 0°C to 60°C, Standard
Market Certifications	CE/FCC
