EPC-WHL-Din Rail

Avalue EPC-WHL-Din Rail 8th Gen Intel Core Fanless Tiny System

EPC-WHL-Din Rail

  • 8th Gen Intel Whiskey Lake-U 4 Core Ultra Low 15W Processor
  • Intel UHD Graphics 620/610
  • Dual Gigabit Ethernet, HD Audio
  • Dual Channel Max up to 64GB DDR4 2400Mhz
  • Dual Expansion, M.2 Key-B/E
  • Dual HDMI w/CEC Controller (Factory Option)
  • TPM 2.0, RAID 0/1
  • Din Rail Type

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

-
+

Details

The Avalue EPC-WHL-Din Rail is a Fanless Tiny System powered by 8th Gen Intel Core processors. The EPC-WHL-Din Rail provides rich I/O including: 4x USB Ports and 2x LAN ports.

Ordering Info

EPC-WHL-86-C2-2R: 8th Gen Intel Core Processor Core i7-8665UE Fanless Din Rail System

EPC-WHL-83-C2-2R: 8th Gen Intel Core Processor Core i5-8365UE Fanless Din Rail System

EPC-WHL-81-C2-2R: 8th Gen Intel Core Processor Core i3-8145UE Fanless Din Rail System

EPC-WHL-43-C2-2R: 8th Gen Intel Celeron 4305UE Fanless Din Rail System

Downloads

Assured Systems Datasheet (PDF)

A PDF edition of this page with supporting manufacturer datasheets

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Processor Type Intel Celeron, up to 2 Cores, Intel Core, up to 2 Cores, Intel Core, up to 4 Cores
GPU Integrated GPU
Memory Capacity Up to 64GB
Cooling Type Fanless
USB Ports 4x USB 3.1
Ethernet Ports (LAN) 2x 1G
Wireless Cellular, Wi-Fi
Video Ports 2x HDMI
Audio Yes
Storage Type 1x 2.5", 1x M.2 SATA
Expansion Type 2x M.2
Input Voltage 12 VDC
Mounting Options DIN-mount
Operating Temperature Wide OT: -10°C to 40°C, Wide OT: -10°C to 50°C, Standard OT: 0°C to 40°C, Standard
Market Certifications CE/FCC
OS Support Linux, Windows 10

Delivery Information

Orders dispatched from Assured Systems USA will be delivered using FedEx.

Payment Methods & Options

Accepted payment methods for US customers include bank transfer, VISA or Mastercard in USD.

Avalue: Warranty and Service Information

Founded in 2011, Assured Systems are an official EMEA Partner of Avalue. For all Avalue products supplied we are proud to offer a comprehensive 2 year warranty, with optional extensions available upon request. Our warranty also covers systems that have been customised by Assured Systems.
