iBOX-316

ASRock Industrial iBOX-316 Intel Celeron N3160 Fanless Embedded BOX PC

iBOX-316

  • Intel Braswell SoC Processor N3160
  • 2 x 204-pin SO-DIMM up to 16GB DDR3L 1600 MHz ( 8GB per DIMM )
  • 1 x mini-PCIe , 3 x USB 3.1 Gen1 , 1 x USB 3.1 Gen1 Type C , 1 x mSATA, 1 x SATA3
  • 1 x Realtek LAN RTL8111G
  • Supports triple display, 2 x HDMI 1.4 , 1 x DP 1.2
  • 1 x 12V/60W AC-DC power brick adapter
  • 135 x 110 x 44.5mm, Fanless Barebon

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

-
+

Details

The ASRock Industrial iBOX-316 is a Fanless Embedded BOX PC powered by Intel Celeron N3160 processor. The iBOX-316 provides up to 16GB memory, alongside rich I/O including 4x USB and 1x LAN port.

Downloads

Assured Systems Datasheet (PDF)

A PDF edition of this page with supporting manufacturer datasheets

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Processor Type Intel Celeron, up to 4 Cores
Memory Capacity Up to 16GB
Cooling Type Fanless
USB Ports 4x USB 3.0
Ethernet Ports (LAN) 1x 1G
Video Ports 1x HDMI, 2x DisplayPort
Audio Yes
Storage Type 1x SATA, 1x mSATA
Expansion Type 1x Mini PCI Express
Input Voltage 12 VDC
Mounting Options VESA-mount
Operating Temperature Wide OT: -20°C to 50°C
Market Certifications CE/FCC
OS Support Windows 10, Windows 7

Delivery Information

Orders dispatched from Assured Systems USA will be delivered using FedEx.

Payment Methods & Options

Accepted payment methods for US customers include bank transfer, VISA or Mastercard in USD.

ASRock Industrial: Warranty and Service Information

Assured Systems, founded in 2011, are an official EMEA Partner of ASRock Industrial. For all ASRock Industrial products supplied we are proud to offer a comprehensive 2 year warranty, with optional extensions available upon request. Our warranty also covers systems that have been customised by Assured Systems.
