FPC-8107-1E2P

Arbor Technology FPC-8107-1E2P 10th Gen Intel Core Robust Box PC w/3x Expansion Slots

FPC-8107-1E2P

  • Fanless design
  • Wide range DC power input (9~36V)
  • Two independent displays support (HDMI x 1 + VGA x 1 and DVI-D x 1)
  • Power on/ off delay control/ configurable ignition power control
  • TPM 2.0 support
  • 1 x mPCIe for optional Wi-Fi/ 3G/ 4G/ GPS or I/O expansion supported
  • Up to 3x expansion slot support
  • 1 x M.2 E Key (2230) for Wi-Fi/ Bluetooth
  • Front-accessible I/O support
  • Intel Wi-Fi 6 AX200 support
  • RAID 0,1 support (W480E optional)

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

-
+

Details

The Arbor Technology FPC-8107-1E2P is a Robust Box PC powered by Intel 10th Generation Core i9/i7/i5/i3 processor. The FPC-8107-1E2P provides rich I/O including: 6x Serial, 8x USB and 3x Ethernet ports, alongside supporting up to 3x Expansion slots.

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Processor Type Intel Core, up to 10 Cores
Memory Capacity Up to 64GB
Cooling Type Fanless
Serial Ports (COM) 2x RS-232/422/485, 4x RS-232
USB Ports 6x USB 3.2, 8x USB 2.0
Ethernet Ports (LAN) 3x 1G
Wireless Cellular, Wi-Fi
Video Ports 1x HDMI, 1x VGA, 1x DVI
Digital I/O 16 DIO
Audio Yes
Storage Type 1x Cfast, 2x 2.5"
Expansion Type 1x PCI Express, 2x PCI
Input Voltage 9-36 VDC
Mounting Options Wall-mount
Operating Temperature Wide OT: -20°C to 55°C, Wide OT: -20°C to 70°C
Market Certifications CE/FCC
OS Support Linux, Windows 10, Windows 11
