ViTAM-112P

Name: Aplex Technology ViTAM-112P 12.1" Stainless Steel Display with 500nit Brightness and Projected Capactive Touch
SKU: ViTAM-112P

Aplex Technology

Aplex Technology ViTAM-112P 12.1″ Stainless Steel Display with 500nit Brightness and Projected Capactive Touch

ViTAM-112P

12.1” New Generation Stainless Steel Display
True Flat Front Bezel Design and Grade 304 Stainless Steel Enclosure (Grade 316 for Option)
IP66/IP69K Rated with M12 (W.F.) Connectors
Support Resistive Touch, Projected Capacitive Touch, and Glass
Touch on/off Button on the Side Edge for Hygienic Cleaning
Support Ergonomic Versatile Mounting: Yoke Mounting / Space-saving VESA 75 x 75 mm Mounting

Choose ViTAM-112 Model:

Product Code: ViTAM-112P

Categories: Aplex Technology, Aplex Technology Industrial Displays, Aplex Technology ViTAM-112 Series, Display Solutions, Industrial Monitors, Stainless Steel Monitors

Range: Aplex Technology - Aplex Technology ViTAM-112 Series

Details

The ViTAM-112 Series is a 12.1" IP66 / IP69K Stainless Steel Display. It has 3 options of brightness 450nit, 500nit and 1000nit. It includes VGA and HDMI inputs with an optional speaker system. It has a default 800x600 resolution and an optional resolution of 1024x768. Touch technology options consisting of PCAP and Resistive Touch. This models operating temperature is 0~50°C, with the ability to alternatively operate at -20~60°C.

Downloads

Datasheet (ViTAM-112P) (PDF)

0.43MB

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Custom Design

Screen Size	11" to 20", 12.1"
Touch Technology	Projected Capactive
Ingress Protection	IP66, IP69K
Stainless Steel	Yes
Brightness	450nit, 500nit, Standard
