IMP-C100-ST-S3-T

Antaira IMP-C100-ST-S3-T Compact 10/100TX To 100FX Industrial PoE+/PSE Media Converter, Single Mode 30KM, ST Connector; EOT -40°C ~ 80°C

IMP-C100-ST-S3-T

  • 1*10/100Tx Fast Ethernet with IEEE 802.3at Compliant PoE+
  • 1*100Fx SC/ST Connector (Multi / Single-Mode)
  • RJ45 Port Support Auto MDI / MDI-X Function
  • Auto Negotiation Speed, Half / Full Duplex
  • Store-and-Forward Switching Architecture
  • Built-in Link Fault Pass Through (LFP)
  • Built-in Far End Fault (FEF)
  • Wide-Range Redundant Power Design
  • Redundant Power Input: 48~55VDC
  • Power Polarity Reverse Protection
  • Overload Current Protection
  • DIN-Rail or Wall Mountable
  • IP30 Protection
  • 5-Year Warranty
-
+

Details

Antaira Technologies’ IMP-C100-XX series is a compact IP30 rated Ethernet-to-fiber media converter featuring a 10/100TX Ethernet port that supports IEEE 802.3at high power PoE that can supply up to 30 watts, and a fixed fiber interface supporting ST and SC connectors depending on the model. There are Multi-Mode and Single-Mode models to support applications with a variety of fiber distances and types. It is designed to fulfill industrial applications that require fiber optic distance extension while using minimal space. The IMP-C100-XX series has a built-in “Link Fault Pass Through” (LFP) and “Far End Fault” (FEF) function with 48~55VDC redundant power inputs with reverse polarity and overload current protection. This product series supports DIN-Rail as well as wall mountable orientations and provides an operating temperature range model in EOT: -40°C to 80°C.

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Delivery Information

Orders dispatched from Assured Systems USA will be delivered using FedEx.

Payment Methods & Options

Accepted payment methods for US customers include bank transfer, VISA or Mastercard in USD.
