MIX-H310A2

AAEON MIX-H310A2 8th/9th Gen Intel Core Mini-ITX Board

MIX-H310A2

  • 8th /9th Gen. Intel Core LGA1151 Processor
  • DDR4 DRAM Support, 2666MHz, Max. 32GB
  • M.2 Slot (M key) x 1, M.2 Slot (E key) x 1
  • USB 3.2 Gen 1 Port x 4, USB 2.0 Port x 2
  • Intel Gigabit Ethernet x 2
  • SATA 6.0 Gb/s x 2
  • PCI-Express [x16] (Gen3) x 1
  • ATX Power

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

-
+

Details

The AAEON MIX-H310A2 is an Industrial Mini-ITX board powered by 8th/9th Gen Intel Core processor. The MIX-H310A2 contains DDR4, providing up to 32GB memory, alongside rich I/O including 6x USB ports, 2x COM ports and 2x LAN ports.

Downloads

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Memory Type DDR4
COM Ports 1x RS-232, 1x RS-232/422/485
LAN Ports 2x 1GB
USB Ports 2x USB 2.0, 4x USB 3.2
Video Ports 1x LVDS, 1x VGA, 1x HDMI, 1x DisplayPort
Storage 1x M.2 PCIe, 2x SATA
Operating Temperature 0°C to 60°C

Delivery Information

Orders dispatched from Assured Systems USA will be delivered using FedEx.

Orders placed by EMEA customers will be delivered by DHL from Assured Systems UK.

Payment Methods & Options

Accepted payment methods for US customers include bank transfer, VISA or Mastercard in USD.

Accepted payment options for EMEA customers include VISA, Mastercard or bank transfer in GBP.

AAEON Technology: Warranty and Service Information

AAEON products purchased in the US and EMEA (including the UK) from Assured Systems come with a 2 year warranty as standard, with additional extended warranty options available. As an official AAEON partner, we are proud to provide customers with peace of mind and the highest quality products.
