GENE-BT06-A12-0003

Name: AAEON GENE-BT06-A12-0003 Intel Atom E3825 3.5” SubCompact Board
SKU: GENE-BT06-A12-0003

AAEON Technology

AAEON GENE-BT06-A12-0003 Intel Atom E3825 3.5” SubCompact Board

GENE-BT06-A12-0003

Onboard DDR3L Memory Max. 4 GB
CRT, 18/24-bit Dual-Channel LVDS LCD, HDMI (DP Sharded with HDMI/CRT, Optional)
Mini-Card Slot x 2 (Full-size x 1, Half-size x 1)
Wide DC Support 9~24V
Supports TPM (Optional)
Solder Design For System Assembly and Thermal

Choose GENE-BT06-A12 Model:

Customisation Service

We can configure this device for you to your exact specification. So we can provide you with the best possible service, please let us know a little about your project if you need this service.

I require customisation *
Please share some background information on your project to help us ensure we’re proposing the best solution *
What processing level is required? *
How much RAM do you require? *
How much storage is required? *
What is the project timeline? *
What operating system would you like to use? *
Do you need any Wi-Fi or Cellular? *
- Wi-Fi
- Cellular
Do you need wide-temperature components? *
- Yes
- No
Do you need a mounting kit? *
Do you need an AC-DC power supply? *
Do you need any additional expansion modules? *

Product Code: GENE-BT06-A12-0003

Categories: 3.5" Single Board Computers, AAEON Embedded Boards, AAEON Technology, Boards & Modules, Industrial Motherboards

Range: AAEON Technology

Details

Building on one of the most popular form factors in today’s computing landscape, the 3.5” GENE-BT06 has everything any in-vehicle solutions has to offer: Soldered connections rather than wired one for sturdiness in high shock/ vibration settings; Wide operable voltages in observation of fluctuating voltages in vehicles; Compactness for easy installation; and different SKUs for users demanding different performance levels. The CPU is now located at the solder side of the board and is accompanied by a heat spreader. Compared with the use of a heat sink in previous models, this change reduces vertical space needed while still retaining effective heat dissipation, making it more conducive for usage in confined spaces. The CPU, along with other components such as RAMs, is soldered onto the board for a sturdier connection when used in high shock/high vibration environments. Observing conditions, such as fluctuating voltages, in vehicles, the board can be powered by a DC voltage with a range of 9 ~ 24V, in addition to the standard input of 12V.A version supporting extended temperature ranges will be forthcoming in the near future. Furthermore, dual display is also provided with the board’s VGA, LVDS, and HDMI interface, while the media being played can be stored using any mSATA device, supported by one of the two PCIe slots.

Downloads

Datasheet (GENE-BT06) (PDF)

0.67MB

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Custom Design

Processor Type	Intel Atom: Up to 2 Ports
Memory Type	DDR3L
COM Ports	2x RS-232/422/485, 2x RS-232
LAN Ports	2x 1GB
USB Ports	1x USB 3.0, 3x USB 2.0
Video Ports	1x VGA, 1x LVDS
Storage	1x mSATA, 1x SATA
Operating Temperature	0°C to 60°C
