WMP-192

Name: 19" Fanless Medical Grade Panel PC with Intel Core 2 Duo CPU
SKU: WMP-192

19″ Fanless Medical Grade Panel PC with Intel Core 2 Duo CPU

End of Life

The WMP-192 is a fanless 19” medical grade panel PC based around Intel's powerful Core 2 Duo U7500 1.06GHz processor. The WMP-192 features a seamless flat resistive touch with IP65 protection, offering easy cleaning and anti-bacterial properties, and the LCD panel offers SXGA resolution of 1280×1024. Features also include a 2.5” drive bay, 2 LAN Ports, four USB, and external VGA output to display content on an external display. Optional WiFi, Bluetooth and optional anti-bacteria desktop stand complete the spec. The system is housed in anti-bacterial plastic ideal for medical environments and also comes with medical 60601-1 3rd edition certification, and satisfies regulations FCC-B, cUL, CE, VCCI required for medical environments.

Brand: Wincomm
Intel Core 2 Duo U7500 1.06GHz CPU
Display: 19″ LED Backlit LCD Panel
Medical 60601-1 3rd edition compliance
1280 x 1024 resolution
350 NITS brightness
Size: 440.5mm (W) x 369.8mm (H) x 83mm (D)

Discontinued
This product is end of life. There may still be stock available; please contact us for more information or suitable replacement solutions.

Product Code: WMP-192

Categories: End of Life Products

Range: Wincomm

Details

The WMP-192 is a fanless 19” medical grade panel PC based around Intel's powerful Core 2 Duo U7500 1.06GHz processor. The WMP-192 features a seamless flat resistive touch with IP65 protection, offering easy cleaning and anti-bacterial properties, and the LCD panel offers SXGA resolution of 1280x1024. Features also include a 2.5” drive bay, 2 LAN Ports, four USB, and external VGA output to display content on an external display. Optional WiFi, Bluetooth and optional anti-bacteria desktop stand complete the spec. The system is housed in anti-bacterial plastic ideal for medical environments and also comes with medical 60601-1 3rd edition certification, and satisfies regulations FCC-B, cUL, CE, VCCI required for medical environments.

Ordering Info

WMP-192: 19″ Fanless Medical Grade Panel PC with Intel Core 2 Duo
Assured Systems will configure and test systems to your exacting requirements, please call our sales team on 01785 879050 to discuss your application in detail

Downloads

WMP-192 Datasheet (PDF)

0.61MB

MPPC Comparison Guide (PDF)

0.04MB

System Integration

Please ask about how we can configure your solution

Global Operations

We deliver and support products via offices globally

Full Warranty

Industry leading warranties on all solutions as standard

Technical Support

Experienced engineers are on hand to support your project

Can't Find What You Want?

Custom Design

Specification

Display: 19″ LED Backlit LCD Panel 1280 x 1024
Brightness: 350 nits
CPU: Intel Core 2 Duo U7500 1.06GHz
Chipset: Intel ICH8M + GME965
Graphics: Integrated Intel Graphics Engine
Memory: 4GB maximum, x 2 DDR2 SODIMM
Audio: Audio Line Out
USB: 2.0 x 4
Storage: 1 x 2.5″ SATA HDD
Expansion: PCI slot x 1, Mini PCIe x 1, Mini PCI x 1
Power: External 100 watts, 90~264V AC in, 12V DC out
Compliance: FCC-B, cUL, CE, VCCI
Medical Regulations: Medical 60601-1 3rd edition (EN 60601-1:2006, ANSI/AAMI ES60601-1:2005, CAN/CSA C22.2 No. 60601-1:
